MBi3511

Intel PGA478M Socket, Core 2 Duo / Core Duo/ Celeron M, Mini-ITX with 2 LAN/ 4 COM/ VGA/ 4 USB/ Audio



​Support Intel® CoreTM Duo/Solo, CoreTM2 Duo (667MHz/533MHz), Celeron® M (533MHz)

mPGA478M

​​Intel® 945GM/945GME Express chipset
Intel® 82801GBM I/O Controller Hub (ICH7M)​
​Two 200-pin SODIMM Sockets

Support 400MHz/533MHz/667MHz DDR2SDRAM, Max. 4GB using 256Mbit, 512Mbit or 1Gbit for x8 and x16 devices​

Award BIOS, 4Mbit flash memory​​

Analog CRT​

Integrated 400MHz RAMDAC

Analog monitor supports up to UXGA

LVDS interface

Panel supports up to UXGA (1600x1200)​

TFT panel supports up to 1x24 bpp (single channel) / 2x24 bpp (dual channel)​​

DVMT 3.0 support

Intel® Dual-Frequency Graphics Technology

Intel® Smart 2D Display Technology

Dual Independent display pipes

Intel Gen 3.5 Integrated Graphics Engine​

Realtek ALC655
16-bit stereo full-duplex codec with independent variable sampling rate
S/PDIF-out interface
5.1-channel audio output​
Two Marvell 88E8053 PCI Express Gigabit controllers
Supports 10Mbps, 100Mbps and 1Gbps data transmission
IEEE 802.3 (10/100Mbps) and IEEE 802.3ab (1Gbps) compliant

Supports two Serial ATA interfaces which are compliant with SATA 1.0 specification (1.5Gbps interface)
Supports AHCI SATA mode
Supports up to two IDE devices, Ultra ATA 100/66/33
1 mini-DIN-6 PS/2 mouse port
1 mini-DIN-6 PS/2 keyboard port
3 DB-9 serial ports
1 DB-15 VGA port
2 RJ45 LAN ports
4 USB 2.0/1.1 ports
Low profile line-in and line-out Rev. BO0 & up
1 CompactFlash socket
2 connectors for 4 additional external USB 2.0/1.1 ports
1 connector for 1 external serial port
1 LCD brightness control connector
1 LVDS LCD panel connector
1 LCD/inverter power connector
1 LCD AUX power connector
1 DIO connector
1 front audio connector for line-out and mic-in jacks
1 CD-in internal audio connector
1 S/PDIF-out connector
1 connector for IrDA interface
2 Serial ATA connectors
1 40-pin IDE connector
1 floppy connector (FPC type)
1 20-pin ATX power connector
1 front panel connector
1 chassis open connector
2 fan connectors
1 PCI slot for PCI expansion card or customized riser card for 1, 2 or 3 PCI slots expansion
0oC to 60oC
10% to 90%
7cm (6.7") x 17cm (6.7")

CPU​

​

​CPU Socket
Chipset





System Memory

​

​

BIOS​​

Integrated Graphics​

​

​

​

​

​

Internal Graphics
​​​​​​​​​​​​​​

​​

​

​

Audio​







​

LAN


SATA


IDE
REAR PANEL I/O






I/O CONNECTORS


















EXPANSION SLOTS​

​

TEMPERATURE
HUMIDITY
Size
